Cutter Slicer Chopper Processor is a classification of equipment that is used to size reduce a wide variety of materials. Cutter, slicer, chopper processing operations can be either done in a batch or continuous manner. This operation can cut the material in several directions to achieve the desired effect in size reduction and consistency. Some machinery has specific operations and has this operation classified to meet a specific operation for size reduction such as a mince master.
Urschel Model M, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and is capable of production rates from 500 to 4,500 lbs per hour – depending on materials and application. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 9" load area on feed belt and adjustable feed roll allowing for positive product feed at all thicknesses from 3/8" to 1". Mounted on a stainless steel frame with casters. Change parts needed for different configurations and size range changes.
OAD: 120"L x 35"W x 50"H
Urschel Model M, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and capable of production rates from 500 to 4,500 lbs per hour – depending on materials and application. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 9" load area on feed belt and adjustable feed roll allowing for positive product feed at all thicknesses from 3/8" to 1". Mounted on a stainless steel frame. Change parts required to accommodate different configurations and size ranges.
OAD 106"L x 32"W x 53"H
Urschel, Model RA-D, stainless steel, USDA approved, wash-down dicer / strip-cutter capable of production rates from 5,000 to 8,000 lbs per hour -depending on materials and application. capable of handling product up to 3-1/2" in any dimension. Slice thickness ranges from 1/16" to 3/8", circular knives range from 1/8" to 1" and crosscut knives range from 1/8" to 1-1/2" spacing (all with proper change parts). Equipped with top-mounted 15” long x 14” wide x 18” deep stainless steel product feed hopper. Control panel has start, stop and safety controllers. Mounted on stainless steel frame with locking casters. Change parts required to accommodate size ranges.
OAD: 55"L x 35"W x 111"H
Urschel, Model M, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and is capable of production rates from 500 to 4,500 lbs per hour – depending on materials and application. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 8½" load area on feed belt. Mounted on a stainless steel frame with casters. Change parts are needed to accommodate configurations and size range changes.
OAD: 92"L x 35"W x 60"H
Urschel, Model LA, stainless steel dicer and slicer, with amount of product per hour – depending on materials and application. Size range: up to 1/2" Slice Thickness; 1/8" to 3" Crosscut; 1/8" to 2" Circular. Accept products up to 3" in any dimension. Equipped with 12" long x 10" wide x 11" deep feed hopper with a 3" x 5" feed throat, 13" x 8" discharge chute with 48" ground clearance, lift off safety guarding. Control panel with start / stop / reset push buttons controls. Mounted on stainless steel base frame. Change parts per application.
OAD: 58"L x 52"W x 83"H
FAM Model ILC, all stainless steel construction, slices, strip cuts and dices up to 2,205 pounds of product per hour – depending on materials and application. Equipped with 18" x 17" stainless steel product feed hopper, 11" OD product port to processing chamber, and has combination of 3 cutting tools for flexibility in choice of cut-sizes and shapes with little juice loss, no cellular damage for smooth cut surfaces, all contributing to extended shelf-life. Cut sizes, Flat slices: 1,60 mm to 28 mm. crinkle slices 3,20 mm to 25 mm. Strip cuttting: circular knife cuts: 2,50 mm to 76 mm, crosscut knife cuts: 4 mm to 64 mm. Dices: flat cut: 3 mm to 64 mm, crinkle cut: 7,10 mm to 16 mm and all knives are changeable for high-capacity production of various applications such as vegetables, fruits and potato processing with proper change parts. Control panel has start, stop and e-stop controls with readout. Mounted on stainless steel frame with interlock safety switch and casters.
OAD: 60" L x 36" W x 46" H
Stephan Machinery, Model VCM-44 A/1, 40 quart vertical bowl chopper. Bowl dimensions: 20" Diameter x 12" Deep. Equipped with hand operated mixing baffle, 4½" long bottom twin chopper / mixing blades, 90° tilt and flip up bolt down cover with safety lock. Powered by a 7½ hp main drive with push button start / stop controls and touch pad display.
OAD: 35"L x 23"W x 54"H
Urschel, Model Diversacut Q, QuantiCut, stainless steel, dicer, slicer, strip cutter with pounds of product per minute and hour – depending on materials and application. Maximum product input size is 10" (254 mm) in any dimension. The Model Q is a higher production model of the model GA. It will slice, strip cut, dice and crinkle cut with a combinations of different slice thickness, with the use of different circular knife spacing and interchangeable crosscut knife spindles. Slice of thickness: 1/8" to 1-1/8" (3.2 to 28.6mm), Circular Knives: 1/4" to 3" (6.4 to 6.2mm) Crosscut Knives: 1/8 to 2-5/8 in. (3.2mm to 66.7mm). Mounted on (4) legs with locking casters. Used for wide variety of products such as potatoes, carrots, turnips, rutabagas, pineapple, peppers, celery and many of other products.
OAD: 72"L x 75"W x 58"H
Gemac Model hydraflaker, stainless steel, frozen block breaker and slicer rated from 1 to 3 blocks per minute – depending on materials and application. Block sizes up to 24" in Length: 24" in width; 10" in Height, Temperatures down to 0 Deg F and can reduce product down to 1/4" thick in 18 to 30 seconds and 1/32" thick in 2 minutes plus (depending on product). Equipped with 32" wide x 36" long product feed table with 26" wide x 7" high hydraulic product ram to 27" long x 22" high product thru opening and 12" OD x 30" long rotary drum cutting assembly with (8) 4-1/2 long blades with flip up, lock down safety cover and 32" long x 16" wide discharge chute with 27" floor clearence. Control panel has machine and feed start, stop and e-stop push button controls. Mounted on stainless steel (4) leg base frame.
OAD: 102" L x 60" W x 55" H
Urschel Model H, stainless steel USDA, dicer / slicer / cutter for a variety of food products with volumes per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 1" Slice Thickness, 3/4" to 1-3/4" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5-1/2" in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls and is mounted on stainless steel base frame. Change parts required for size changes. Currently set for
Urschel Model 1700 Comitrol, stainless steel, reduction mill for free flowing dry and semi-dry product with number of pounds of product per hour – depending on materials and application. Equipped with 12" ID x 12" Deep product hopper 17" OD x 17" milling chamber with (3) 3" dog leg style high speed rotating impeller and cutting head with vertical blades and 4-1/2" OD triclover product inlet and 3-1/2" triclover product discharge with 30 Hp motor drive. Control panel has push botton start, stop, auto and manual control switches. Mounted on stainless steel base frame. Operations include communiting, granulating, milling, slicing, liquifying, dispersing, and pureeing.Change parts required per application.OAD: 48" W x 33" L x 66" H
Gemac Model 2501 Hydraflaker, stainless steel, frozen block breaker rated from 1 to 3 blocks per minute – depending on materials and application. Block sizes up to 24" in Length: 24" in width; 10" in Height, down to 0 Deg F and can reduce product down to 1/4" thick in 18 to 30 seconds and 1/32" thick in 2 minutes plus (depending on product). Equipped with 30" wide x 69" long product feed table with 22" wide x 6-1/2" high hydraulic product ram to 28" long x 12" OD (8) blade rotary drum cutting assembly has flip up safety cover with interlock shut-off and 30" wide discharge chute with 28" floor clearence. Mounted on (4) leg base frame.
OAD: 92" L x 52" W x 55" H
