Home » Mixer Powder » Ribbon S. S.
Stainless steel ribbon powder blenders or mixers have been the most widely used mixers for both dry powders and incorporating some liquids into a dry mixture. Stainless steel ribbon powder mixers can handle a wide variety of product and sizes for making good mixtures. Stainless steel ribbon powder mixers usually are the slowest type of mixers to achieve the required mixture but they do not generate high heat and can actually unmix materials if left in the mixing mode for too long a period. The materials of construction can be carbon steel with total dry mixes and non-corrosive materials to all stainless steel and other specialty steels for maintaining the integrity of the mixer.
Morcos Machinery Model RM1000, stainless steel, double ribbon mixer with pounds of product per hour – depending on materials and application. 304L stainless steel construction. Has Maximum bowl capacity of 1000 Litres, (35.31 ft³) with minimum mixing capacity of 441 litres (14.51 ft³) and maximum mixing capacity of 833 litres (29.41 ft³). Mixing chamber dimensions: 70" in Length; 34" in Width; 33" in Depth. Equipped with flip up / clamp down cover, with micro-switch safety switch and safety grate with seals for powdered products and 8" OD top product port. (2) levels of spirals, (1) internal anticlockwise and (1) external clockwise has 2" wide x (1/8)" thick (outer) and 2" wide x (1/8)" thick (inner) stainless steel ribbons (2) levels spirals, (1) internal anticlockwise and (1) external clockwise spiral.powered by 7.3 Hp motor drive. 10 OD center bottom pneumatic discharge gate with 24 ground clearence. Control panel has start, stop push button controls. Mounted on (4) leg stainless steel frame.Also granule product with crystal size ranging from 450 microns (17.71 mil.) till 650 microns (25.59 mil.).
OAD: 100" L x 34" W x 782" H
Morcos, Model RM600, 21 ft³, (17 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 60" in Length; 24" in Width; 26" in Depth. Equipped with flip up cover, lift out safety screens, 2¼" OD motor shaft, 1¾" wide x ¼" thick (outer) and 1¾" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 7.38 Hp motor. Mounted on stainless steel (4) leg frame with 35" wide x 121" long stainless steel platform set 57" off the ground with 36" high rails and a 6-step staircase.
OAD: 125"L x 102"W x 103"H
Sprout Waldron, model B-79, 94 ft³, (79 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel construction. Inner mixing chamber dimensions of 119" in Length; 38" in Width; 40" in Depth. Equipped with lift up cover, 2" wide x ¾" thick (outer) and 4" wide x ½" thick (inner) stainless steel ribbons. 7" diameter flush pneumatic dischage with 38" ground clearance. Ribbons powered by a 15 HP drive.
OAD: 151"L x 50"W x 94"H
Morcos, Model RM1000, 40 ft³, (35 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 76" in Length; 30" in Width; 33" in Depth. Equipped with flip up cover, lift out safety screens, 2¾" OD motor shaft, 2" wide x ¼" thick (outer) and 2½" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 14.75 Hp motor. Mounted on stainless steel (4) leg frame with 41" wide x 143" long stainless steel platform set 70" off the ground with 36" high rails and a 7-step staircase.
OAD: 146"L x 109"W x 114"H
10 ft³, (7 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 43" in Length; 18" in Width; 22" in Depth. Equipped with flip up cover, lift out safety screen, 1½" OD motor shaft, 1" wide x ¼" thick (outer) and 1(1/8)" wide x ¼" thick (inner) stainless steel ribbons. 3" OD center bottom discharge with slide gate valve and 49" floor clearence. Powered by a 1½ Hp motor. Mounted on stainless steel (6) leg frame with a 40" x 32" standing platform.
OAD: 91"L x 63"W x 87"H
22 ft³, (20 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 72" in Length; 24" in Width; 30" in Depth with a 18" straight wall. Equipped with flip up cover, lift out safety screens, 2½" OD motor shaft, 1½" wide x ¼" thick (outer) and 2" wide x ¼" thick (inner) stainless steel ribbons. 8" x 8" bottom discharge with 62" floor clearence and Eriez magnetic separator. Mounted on stainless steel (4) leg frame.
OAD: 124"L x 34"W x 94"H
40 ft³, (35 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 76" in Length; 32" in Width; 36" in Depth with a 21" straight wall. Equipped with sliding cover, lift out safety screens, 3" OD motor shaft, 1½" wide x ?" thick (outer) and 4¼" wide x ¼" thick (inner) stainless steel ribbons. 8" OD bottom discharge with 58" floor clearence and 15 Hp motor. Mounted on stainless steel (4) leg frame.
OAD: 162"L x 42"W x 102"H
Morcos, Model RM2000, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 51" floor clearence and 20 Hp motor. Mounted on stainless steel (4) leg frame with 48" wide x 168" long stainless steel platform with an 8-step staircase.
OAD: 172"L x 124"W x 117"H
Morcos, Model RM2000, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 51" floor clarence and 20 Hp motor. Mounted on stainless steel (4) leg frame with 48" wide x 168" long stainless steel platform with an 8-step staircase.
Morcos, Model RM1000, 35 ft³, (30 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 71" in Length; 28" in Width; 31" in Depth. Equipped with flip up cover, lift out safety screens, 2¾" OD motor shaft, 2" wide x ¼" thick (outer) and 2½" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 12.3 Hp motor. Mounted on stainless steel (4) leg frame with 40" wide x 133" long stainless steel platform set 67" off the ground with 36" high rails and a 7-step staircase.
OAD: 136"L x 103"W x 109"H
