Stainless steel ribbon powder blenders or mixers have been the most widely used mixers for both dry powders and incorporating some liquids into a dry mixture. Stainless steel ribbon powder mixers can handle a wide variety of product and sizes for making good mixtures. Stainless steel ribbon powder mixers usually are the slowest type of mixers to achieve the required mixture but they do not generate high heat and can actually unmix materials if left in the mixing mode for too long a period. The materials of construction can be carbon steel with total dry mixes and non-corrosive materials to all stainless steel and other specialty steels for maintaining the integrity of the mixer.
Mepaco, 304 stainless steel, dual trough ribbon blender. Capacity: 140 ft³ total (110 ft³ working). with pounds of product per hour – depending on materials and application. Dual trough with mixer dimensions of: 102" in Length; 32" in Width; 43" in Depth each trough. Equipped with lift up safety grate, 3½" wide x ½" thick ribbons, dual 22" x 10" pneumatic gate discharges with 53" ground clearance and powered by (2) motor drives. Mounted on heavy duty frame.
OAD: 163"L x 72"W x 105"H
10 ft³, double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts with Inner mixing chamber dimensions of: 43" in Length; 22" in Width; 25" in Depth. Equipped with lift up cover, lift out safety grate, (4) nozzle spray bar, 2¼" OD mixing shaft with 1½" wide x ¼" thick (outer) and 1½" wide x (1/8)" thick (inner) stainless steel ribbons. 4" center bottom discharge with pneumatic slide gate and 8" x 8" discharge chute with 36" ground clearance. Mounted on (4) leg frame with casters.
OAD: 64"L x 26"W x 75"H
Morcos, Model RM1200, 40 ft³, (35 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 76" in Length; 30" in Width; 33" in Depth. Equipped with flip up cover, lift out safety screen, 2¾" OD motor shaft, 6" OD mixing shaft with 2½" wide x ¼" thick (outer) and 2½" wide x ¼" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 23" floor clearence and 14.75 Hp motor. Mounted on stainless steel (4) leg frame.
OAD: 106"L x 40"W x 78"H
Morcos, Model RM200, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 23" floor clearence and 20 Hp motor. Mounted on stainless steel (4) leg frame.
OAD: 124"L x 46"W x 89"H
S Howes Co Inc, 10 ft³, 316 Stainless steel, double ribbon mixer with pounds of product per hour – depending on materials and application. Finish: #180 grit polish. Internal dimensions: 48" in Length; 24" in Width; 24" in Depth. Equipped with flip up clamp down cover and has 14" OD center inlet with safety interlocks, 2" outer and 1" inner wide double interrupted ribbons mounted on a 3-1/2" OD shaft. 7" OD, 4-1/2" ID sanitary center bottom discharge with butterfly valve. Control panel with touch pad variable speed frequency controls, air purge seals. Mounted on (4) legs.
OAD: 84" L x 44" W x 80" H
Paul O Abbe, Model RB-10, 10 ft³, 304 stainless steel, double ribbon mixer. Inner mixing chamber dimensions of: 39" in Length; 22" in Width; 25" in Depth. Equipped with top mounted product feed hopper with safety grate and flip up / clamp down interlock safety cover and 5 Hp drive. Bottom pneumatic flap valve discharge has 16" x 12" flanged bottom and 10" x 3" ID of chute discharge with 35" ground clearence. Variable speed and e-stop. Rate dependent on materials, machine configuration and application.
OAD: 73"L x 38"W x 82"H
Paul O Abbe, Model RB-10, 10 ft³, double ribbon mixer with amount of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of: 39" in Length; 22" in Width; 25" in Depth. Equipped with top mounted product feed hopper with safety grate and flip up / clamp down interlock safety cover and 1½" wide x (3/8)" thick (outer) and 2" wide x ¼" thick (inner) stainless steel ribbons double ribbons powered by 5 Hp drive. Bottom pneumatic flap valve discharge has 16" x 12" flanged bottom with 35" ground clearence. Controls have valve open / close switch and variable speed control and e-stop. Mounted on heavy duty frame.
Ross, Model 42N-005, 7 ft³ (5 ft³ workable), double ribbon mixer with amount of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of: 38" in Length; 17" in Width; 21" in Depth. Equipped with flip up cover, 2½" OD mixing shaft with 1" wide x ¼" thick (outer) and 1½" wide x (1/8)" thick (inner) stainless steel ribbons powered by 10 Hp drive. 3" OD center bottom discharge has slide gate valve with 36" ground clearance.
OAD: 67"L x 32"W x 74"H
Reitz, Model RS-18K5405, Stainless steel 28 ft³ total / 20 ft³ working capacity, twin ribbon mixer with pounds of product per hour – depending on materials and application. Mixing chamber inner dimmensions; 60" in Length; 36" in Width; 25" in Depth total, with dual flip safety grates. Equipped with dual mixing troughs and mixing ribbons set on 4" OD shafts with 2" wide x ½" thick ribbons, dual 5 Hp motor drives with safety guarding and dual air operated end bottom product discharge doors with 36" floor clearance. Mounted on (4) leg base frame.
OAD: 94" L x 55" W x 64" H
Morcos Machinery Model RM600, stainless steel, double ribbon mixer with pounds of product per hour – depending on materials and application. 304L stainless steel construction. Has Maximum bowl capacity of 600 Litres, (21.18 ft³) with minimum mixing capacity of 268 litres (9.464 ft³) and maximum mixing capacity of 500 litres (17.657 ft³). Mixing chamber dimensions: 60" in Length; 24" in Width; 30" in Depth. Equipped with flip up / clamp down cover, with micro-switch safety switch and safety grate with seals for powdered products and 6" OD top product port. (2) levels of spirals, (1) internal anticlockwise and (1) external clockwise has 1¾" wide x (1/8)" thick (outer) and 1¾" wide x (1/8)" thick (inner) stainless steel ribbons powered by 7.3 Hp motor drive. 8" OD center bottom pneumatic discharge gate with 24" ground clearence. Control panel has start, stop push button controls. Mounted on (4) leg stainless steel frame.Granule product with crystal size ranging from 450 microns (17.71 mil.) till 650 microns (25.59 mil.).
OAD: 92" L x 30" W x 64" H
Morcos Machinery Model RM1000, stainless steel, double ribbon mixer with pounds of product per hour – depending on materials and application. 304L stainless steel construction. Has Maximum bowl capacity of 1000 Litres, (35.31 ft³) with minimum mixing capacity of 441 litres (14.51 ft³) and maximum mixing capacity of 833 litres (29.41 ft³). Mixing chamber dimensions: 70" in Length; 34" in Width; 33" in Depth. Equipped with flip up / clamp down cover, with micro-switch safety switch and safety grate with seals for powdered products and 8" OD top product port. (2) levels of spirals, (1) internal anticlockwise and (1) external clockwise has 2" wide x (1/8)" thick (outer) and 2" wide x (1/8)" thick (inner) stainless steel ribbons (2) levels spirals, (1) internal anticlockwise and (1) external clockwise spiral.powered by 7.3 Hp motor drive. 10 OD center bottom pneumatic discharge gate with 24 ground clearence. Control panel has start, stop push button controls. Mounted on (4) leg stainless steel frame.Granule product with crystal size ranging from 450 microns (17.71 mil.) till 650 microns (25.59 mil.).
OAD: 100" L x 34" W x 82" H
