Baker Perkins / B & P Process Equipment, 10 cubic foot (80 gallon), carbon steel, double sigma mixer with amount of product per hour – depending on materials and application. Internal mixing chamber dimensions of: (30" in Length x 26" in Width x 26" in Depth. Equipped with full hinged cover and (2) 3 1/2" OD sight glasses, double sigma mixing blades, hydraulic tilt discharge and double end motor drive with jacketed side plates. Control panel has start, stop and e-stop controls. Mounted on heavy duty carbon steel frame.
OAD: 102" L x 72" W x 50" H
100 gallon jacketed, C/S double sigma mixer. Internal mixing chamber dimensions: (26"L x 30"W x 22"Deep). Equipped with hinged flip top cover, hydraulic tilt, and 20 HP Allis Chalmers double end drive. Mounted on a mild steel base.
OAD: 88"(L) x 64"(W) x 58"(H)
Baker Perkins, 15 ft³, dual sigma jacketed mixer. Internal mixing chamber dimensions of 33" long x 38" wide x 30" deep for a working capacity of 75 gallons. Equipped with 5" wide dual sigma blades powered by a 40 Hp drive, hydraulic tilt discharge with a 27" discharge height. Mounted on a painted base frame.
Jacket Fittings:(7) 3/8" NPT
OAD: 101"L x 78"W x 61"H
Baker Perkins, Model 0.1 ft³ (¾ gallon) working capacity, jacketed, 304 stainless steel, double arm, sigma blade mixer with pounds of product per hour – depending on materials and application. Inner mixing chamber dimensions: 5¼" in Length; 7" in Width; 9" in Depth. Equipped with stainless steel contact parts, 2 Hp motor drive, hand tilt with 34" discharge height and ¼" NPT connections for low pressure jacket. Mounted on a painted base frame with push button start / stop controls and run / jog switch.
OAD: 48"L x 36"W x 58"H
Baker Perkins, Model 0.1 ft³ (¾ gallon) working capacity, jacketed, carbon steel, double arm, sigma blade mixer with pounds of product per hour – depending on materials and application. Inner mixing chamber dimensions: 5½" in Length; 7¼" in Width; 7" in Depth. Equipped with carbon steel contact parts, bolt down cover with pressure guage, 2 Hp motor drive, hand tilt with 30" discharge height and (3/8)" NPT connections for low pressure jacket. Mounted on a painted steel base frame with push button start / stop controls.
OAD: 40"L x 24"W x 41"H
Baker Perkins, 2 Gal, dual sigma blade, jacketed lab size mixer with 316 stainless steel contact parts. Mixing chamber dimensions: 9" long x 8½" wide x 8" deep. Equipped with an 11" x 11" lift up cover, low pressure jacket, 1½ hp dive and manual tilt handle. Unit mounted on a mild steel base.
OAD: 40" L x 28" W x 46" H
