Filamatic, Model MNB-2000, Monoblock filler, tipper and capper. Rated from 20 to 60 containers per minute – depending on materials, application and machine configuration. Fill range of 0.5ml to 150ml with proper change parts. Equipped with a two head piston filler, 15" diameter vibratory feed bowl for tips, single head tip placer, 21" diameter vibratory feed bowl for caps, single head cap placer and single head cap press. Mounted on base frame with light curtain safety guarding.
OAD: 72"L x 58"W x 79"H
Filamatic, Model V-300, (8) head, automatic inline stainless steel, piston filler. Rated up to 200 containers per minute – depending on materials, application and machine configuration. Equipped with 190" long x 3" wide container conveyor has star wheel indexing with adjustable guide rails, (8) filling heads with (8) XL-560 cc FKS pistons and (8) ¼" OD diving nozzles for bottom up fill mounted on 29" long slide bar with a fill range from 26ml to 560ml. Accuracies of + / – 0.5% and is capable of handling free flowing to viscous products in a variety of container sizes and shapes, all with the proper change parts. 45 gallon stainless steel product tank with a 24" diameter x 24" deep vessel dimension. Control system has conveyor and machine speed dials, push button start, stop, reset and e-stop controls. Mounted on stainless steel frame with safety door guarding and leveling legs.
OAD: 192" L x 66" W x 72" H
Filamatic, Model SNY-32-4, 10 head, inline, piston filler with amount of product per minute / hour – depending on materials and application. Stainless steel contact parts. Fill range of up to 1100ml (37oz) with proper change parts. Equipped with 183" long x 4½" wide Delrin container conveyor, has pneumatic indexing, adjustable guide rails, with 10 pistons and diving nozzles has accuries of + / – 1% on 24" long slide bar. Control panel has push button start, stop and e-stop controls. Mounted on heavy duty frame with leveling legs. Change parts required to accommodate different fill ranges.
OAD: 33" L x 45" W x 70" H Filler 207" L x 29" W x 55" H Conveyor
Filamatic, Model H-300, 8 head, inline, piston filler. Stainless steel contact parts. Fill range of 1ml to 1100ml with proper change parts Equipped with 96" long by 4½" wide Delrin conveyor, pneumatic indexing, adjustable guide rails, (8) 360cc pistons and (8) ½" OD diving nozzles mounted on 35" long slide bar. Control panel has push button start, stop and e-stop controls. Mounted on base frame with leveling legs. Speed dependent on materials, application and machine configuration. Change parts required to accommodate fill range.
OAD: 96"L x 60"W x 72"H
Filamatic Model MNB-2000, 1-up, Automatic, monoblock filler, tipper and capper rated 10 to 50 containers per minute – depending on materials and application, 316 stainless steel product contact parts, Container size range: 1/2" to 2-14" in Diameter; 1" to 5" in Height. Fill range: 0.5ml to 500ml with accuracies of + / – 0.5% and can handle low, moderate and high viscosity products with proper change parts. Equipped with empty container feed system with container chute, 16 pocket container carousel with 1-up filler, dual vibratory stainless steel tip and cap feed hoppers with single head screw capper, bottom up fill and missing bottle, tip, cap detection and Seko guages. Touch pad controller with panel view and operator interface data information control system has reset, start, stop and e-stop push buttons. Mounted on stainless steel frame with interlock safety door guarding and Hepa filtration system.
OAD: 80" L x 54" W x 82" H
Filamatic, Model DAB 32-4, (4) head, inline stainless steel piston filler. Equipped with 120" long x 4-1/2" wide Delran conveyor, 24" long x 12" wide x 19" deep product hopper, 1000ml FUS pistons, 1/2" OD positive cut-off, diving nozzles mounted on 17" long slide bar and drip tray. AB PLC. Controls for auto / prime, filler, belt and pump on / off switches and e-stop. Mounted on casters with leveling legs. Speed dependant on materials, application and machine configuration.
OAD: 120" L x 48" W x 96" H
Filamatic Model DAB-32-2, heavy duty, semi-automatic, all stainless steel, (2) head piston filler. Currently equipped with (2) 1100ml pistons, 12" long slide bar with (2) 7" long x 3/4" OD fill nozzles, Control panel has main machine switch, auto prime, suck back adjustment, dual speed and bottom up fill speed as well as machine speed control dials. Mounted on all stainless steel platform style base with casters, leveling legs and safety guarding. Speed dependent on materials, application and machine configuration.
OAD: 48" L x 40" W x 60" H
Filamatic, Model DAB-16, 2 head inline piston filler. Rated from 12 to 60 bottles per minute with a fill range of 60ml to 520ml with proper change parts – depending on materials, application and machine configuration. Equipped with 100" long by 3¼" wide Delrin conveyor, star wheel indexing and (2) 520cc FUS pistons. Mounted on base frame with leveling legs.
OAD: 105"L x 40"W x 63"H
Filamatic, Model S-16, 4 head inline piston filler. Equipped with 90" long by 3¼" wide Delran conveyor, star wheel indexing, (4) 130cc FUS pistons and (4) (¼)" OD diving nozzles. Speed dependant on materials, application and machine configuration.
OAD: 96"L x 58"W x 60"H
Filamatic, Model DAB 32-2, semi automatic two head table top piston filler. Equipped with two 550cc DUS-HP pistons and 7/16"OD nozzles. Control panel with variable speed dial and foot pedal cycle. Rated/ Speed dependant on materials, application, machine configuration and operator dexterity.
OAD: 37"L x 32"W x 61"H
Filamatic, Model SYN-32-4, automatic, 4 head piston filler. Equipped with 3-1/2" wide conveyor, gate indexing system, 1100 ml pistons and diving nozzles. A/B controller with start, stop and e-stop push buttons, auto, prime, conveyor on / off and multi-stroke switches, filler and conveyor speed controls. Mounted on height adjustable legs. Stainless steel contact parts. Speed dependant on materials, application and machine configuration.
OAD: 112" L x 43" W x 67" H
Filamatic, Model H-Z-300, automatic, 4 head piston filler with number of containers per minute – depending on materials and application. Stainless steel contact parts. Fill range up to 1100cc with proper change parts. Equipped with 3-1/2" wide x 112" long delron product conveyor, pneumatic indexing, diving nozzles. Control panel with controller has auto, prime, conveyor on / off and multi-stroke switches, filler control dial and start, stop and e-stop push buttons. Mounted on stainless steel base frame. With the FVS series pistons designed for use with viscous products can handle water thin liquid to viscous products as creams and gels also with particulates with proper feed system.
