Home ยป Fogg
Fogg, automatic, stainless steel, monoblock system with waterfall style cap sorter / feeder, 32 head rotary cleaner, 24 head rotary pressure gravity filling, 8 head rotary capper and HEPA filtration system. Rated from 50 to 240 containers per minute – depending on materials and application. Waterfall style capp sorter and feeder equipped with a 32" x 43" x 28" hopper, 18½" wide belt with ½" high cleats on 4" centers. Equipped with 4½" wide container conveyor, worm screw to star wheel in feed and discharge, (32) head cleaner with nozzles on 8¾" centers, (24) fill to level nozzles set on 8¾" centers, 8 head rotary capper withchuck style cap heads set on 8¾" centers. Control panel has AB controls with a touch screen HMI.
OAD: 84"L x 40"W x 144"H – Cap Sorter 137"L x 112"W x 80"H – Cleaner 131"L x 135"W x 144"H – Filler / Capper
Fogg, automatic, stainless steel, monoblock system with waterfall style cap sorter / feeder, 36 head rotary pressure gravity filling, 10 head rotary capper and HEPA filtration system. Rated from 50 to 325 containers per minute – depending on materials and application. Waterfall style capp sorter and feeder equipped with a 32" x 40" x 33" hopper, 17" wide belt with ½" high cleats on 2" centers. Filler equipped with 3¼" wide container conveyor, worm screw to star wheel in feed and discharge, (36) fill to level nozzles set on 3¾" centers, 10 head rotary capper with (10) chuck style cap heads set on 4½" centers and CIP nozzles / ring. Control panel has AB controls with a touch screen HMI.
OAD: 100"L x 36"W x 156"H – Cap Sorter 147"L x 103"W x 147"H – Filler / Capper
28 Head, stainless steel, gravity pressure filler. Containers size: up to 5" in Diameter; up to 10-3/4" in Height. Equipped with screw to star wheel in feed, 5/8" nozzles set on 5-1/2" centers, with centering guides, no bottle / no fill and star wheel discharge. Conveyor track designed to integrate into existing convey system. Speeds dependant on materials and application.
OAD: 76"L x 75"W x 92"H
Automatic, stainless steel, 32-head, rotary, gravity / pressure filler rated 80 to 320 bottles per minute, depending material and application. Has 4 1/2" pitch, 5/8" diameter fill-to-level nozzles, wormscrew infeed, starwheel infeed / discharge, neck centering bells, 4"L x 4 3/8"W container platforms, and 100 gallon product hold tank. Mounted on stainless steel frame with height adjustable legs.
OAD: 57"L x 75"W x 80"H
Federal, Model 3615, Automatic, 316 stainless steel, 56 head rotary, pressure gravity filler rated from 56 to 200 containers per minute – depending on materials and application. Equipped with 72" long x 3-1/2" container conveyor has worm screw to star wheel container in feed and discharge, 64" turrett with (56) J3 double diapragm 3/4" OD fill to level nozzles, set on 4" centers with 3" x 5" container platforms and 60" OD x 16" Deep product holding tank with CIP ring. Capper capable (no cap heads) Control panel has A/B PLC with filler start, jog, speed, bowl, capper, no cap and bottle back-up with, start and e-stop push buttons. Mounted on heavy duty stainless steel frame. Capable of running bottled water, juice, tea and both cold or hot fills.
OAD: 128" L x 80" W x 78" H
Fogg, Model FAA-3618, automatic, stainless steel, 36 head rotary, pressure gravity filler and 18 head rotary capper. Rated from 50 – 325 containers per minute – depending on materials and application. Equipped with a 3¼" wide container conveyor, worm screw to star wheel in feed and discharge, 48" turrett with (36) ¾" OD fill to level nozzles, set on 3¾" centers with 5" long x 3" wide container platforms, 48" OD product holding tank and 18 head rotary capper with (18) ____ style cap heads set on 4½" centers. Control panel with push button start / stop for filler and conveyor; push button jog, variable speed filler speed dial, on / off switches for cap sensor and bottle back up sensor, up / down switches for bowl and capper. Mounted on stainless steel base frame.
OAD: 91"L x 86"W x 82"H
