Automatic 1 by 3 in-line cup filler. Size range: up to 5" in Diameter; up to 7" in Height. Equipped with denest station, three 32 ounce pistons with rotary valves, over lid station and discharge. Speed dependant on materials and application.
OAD= 156" L x 46" W x 87" H
Automatic, S/S, 1 x 3 , USDA – wash down, intermittent motion piston style cup filler. Capable of a container size range to 5" diameter and height to 7 ". Equipped with 32 ounce piston with rotary valve capable of down to a 7.25oz fill. Shuttle type overlidder with magazine that are well suited for the "tamper evident " and flat style lids. Automatic container eject. Unit will denest container from a magazine, fill product, overlid and discharge container. Can be used with either paper or plastic containers. Last running in a dairy operation. OAD= 156"L x 46"W x 87"H
Holmatic Model OF-2340, Automatic, 4-up, inline cup filler, roll stock film, die cutter, heat sealer and over lidder rated 10 to 40 indexes per minute with number of cups – depending on materials, application and machines configuration. All stainless steel and anodized aluminum construction. Cup size: up to 5" in Diameter; and 6-1/4" in Height. Fill size: up to 41oz + / – 0.5%, both with proper change parts. Equipped with (4) lane 32" long automatic belt fed empty cup magazines and denesters, cup conveyor has 22-1/2" long plates with (4) across 4-1/2" ID cup pockets set on 6" centers, (4) 7" long x 2" OD pistons with rotary valves and 1-1/2" OD positive shut off nozzles, 23" long roll stock film rollers with (4) die cutters, heat sealers and cup over lid magazines, with spinning roller over lid applicator. Control panel has A/B controller with A/B Panelview and (4) heat sealer controllers, with system reset, cycle, e-stop push button controls and statis light bar. Mounted on stainless steel frame with interlocking cage style safety guarding and leveling legs..
OAD: 192" L x 72" W x 107" H
Holmatic / Oystar, Model PH-41SB, Automatic, vertical snap, over lid applicator. Stainless steel and anodized aluminum construction. Equipped with 48" long spinning rod lid magazine, 4½" wide x 90" long Delrin belt, star wheel infeed and 3½" wide x 16" long container transfer conveyor. Speed dependent on materials, application and machine configuration.
OAD: 110"L x 24"W x 60"H
Holmatic Model PR4, Automatic, 4-up, cup filler, die cutter, heat sealer and over lidder rated from 20 to 160 cups per minute – depending on materials and application. Stainless steel and hard anodized aluminum construction. Cup size: up to 4½" in Diameter; and 6" in Height. Fill size: up to 41oz both with proper change parts. Equipped with (4) cup magazines with spiral cup denesters, product hopper and feeders, cup conveyor currently set with (4) across 3¼" OD cup pockets set on 6" centers, (4) pistons with rotary valves and ¾" OD positive shut off nozzles, roll stock film with die cutters, heat sealers and cup over lid magazines, with reciprocating vacuum pick n place and spinning roller over lidder. Control panel has A/B PLC, controller with A/B Panelview and conveyor, cup dispenser, heat, filler, overcapper and cap station cycle stop controls with (4) heat sealer controllers and e-stop. Mounted heavy duty frame stainless steel frame with interlocking Lexan safety guarding.
OAD: 167" L x 62" W x 109" H
Holmatic, Model CBS-36, automatic, intermittent motion, inline, two station, 8 head, container sealer. Rated From 30 to 160 containers per minute – depending on materials and application. Container Size: 38mm to 127mm in Diameter; 76mm to 203mm in Height; Rectangular Container 38mm to 114mm in Length and Width. Equipped with a 96" long x 4.5" wide Delrin infeed conveyor, starwheel index, rotary product pusher, 168" long adjustable chain carrier system, dual 4-head sealing stations, no container no seal, auto film unwind/rewind with splicing station, interlocking Lexan safety guarding and a 60" long discharge conveyor.. Control panel with A/B PLC and A/B touch screen HMI. Mounted on height adjustable legs.
OAD: 274"L x 76"W x 88"H
Holmatic Model PR-3S, 3 lane, inline, stainless steel, cup filler, roll stock film sealer rated from 30 to 120 cups per minute – depending on materials, application and machine configuration. Sanitary stainless steel and hard anodized aluminum construction. Container size range: 5" to 7" in Diameter; up to 7.3" in Height. Fill volume up to 90oz each head. Change parts required to accommodate different sizes. Equipped with 180" long cup conveyor has 8-3/4" long x 24" wide carrier plates currently set with (3) 4-1/4" OD cup pockets set on 9" centers, cup de-nest station, 30" long x 17" wide x 24" deep, stainless steel, jacketed, agitated product hopper, (3) head piston filler, with (3) 15" long x 2-1/4" ID pistons, and 2-1/4" OD nozzles (change part per application) no container / no fill, automatic film roll stock feeder and rewinder with die cut heat sealing stations. Control panel has A/B PLC controller with A/B onboard panelview and operator read out (3) heat seal, start, stop, e-stop controls. Mounted on stainless steel frame with cage style safety guarding. Mounted on stainless steel frame with cage style safety guarding. Recommended for wipedown environments, applications range from hard candy to dry soup and snack foods to pet treats.
OAD: 193" L x 92" W x 91" H
Holmatic Model PR-3S, 3 lane, inline, stainless steel, cup filler, roll stock film sealer rated from 30 to 120 cups per minute – depending on materials, application and machine configuration. Sanitary stainless steel and hard anodized aluminum construction. Container size range: 5" to 7" in Diameter; up to 7.3" in Height. Fill volume up to 90oz each head. Change parts required to accommodate different sizes. Equipped with 180" long cup conveyor and has 8-3/4" long x 24" wide carrier plates with (3) 4-1/4" OD cup pockets set on 9" centers, cup de-nest station, 30" long x 17" wide x 24" deep, stainless steel, jacketed, agitated product hopper, (3) head piston filler, with (3) 15" long x 2-1/4" ID pistons, and 2-1/4" OD nozzles (change part per application) no container / no fill, automatic film roll stock feeder and rewinder with die cut heat sealing stations. Control panel has A/B PLC controller with A/B onboard panelview and operator read out (3) heat seal, start, stop, e-stop controls. Mounted on stainless steel frame with cage style safety guarding. Mounted on stainless steel frame with cage style safety guarding.Recommended for wipe down environments, applications range from hard candy to dry soup and snack foods to pet treats.
OAD: 180" L x 80" W x 84" H
Holmatic Model PR-3S, 3 lane, inline, stainless steel, tray filler, roll stock film sealer rated from 30 to 120 trays per minute – depending on materials, application and machine configuration. Sanitary stainless steel and hard anodized aluminum construction. Container size range: per application. Fill volume up to 90oz each head. Change parts required to accommodate different sizes. Equipped with 180" long cup conveyor has 8-3/4" long x 24" wide carrier plates with (3) 7-3/4" long x 5-1/2" wide rectangle tray pockets set on 9" centers, tray de-nest station, 30" long x 17" wide x 24" deep, stainless steel, jacketed, agitated product hopper, (3) head piston filler, with (3) 15" long x 2-1/4" ID pistons, and 2-1/4" OD nozzles (change part per application) no container / no fill, automatic film roll stock feeder and rewinder with die cut heat sealing stations. Control panel has A/B PLC controller with A/B onboard panelview and operator read out (3) heat seal, start, stop, e-stop controls. Mounted on stainless steel frame with cage style safety guarding. Recommended for wipedown environments, applications range from hard candy to dry soup and snack foods to pet treats.
OAD: 190" L x 72" W x 84" H
OAD: 180" L x 80" W x 90" H
Piston Filler for Holmatic.
