Home » Morcos » Page 2
Morcos, Model RM2000, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 51" floor clearence and 20 Hp motor. Mounted on stainless steel (4) leg frame with 48" wide x 168" long stainless steel platform with an 8-step staircase.
OAD: 172"L x 124"W x 117"H
Morcos, Model RM2000, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 51" floor clarence and 20 Hp motor. Mounted on stainless steel (4) leg frame with 48" wide x 168" long stainless steel platform with an 8-step staircase.
Morcos, Model RM1000, 35 ft³, (30 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 71" in Length; 28" in Width; 31" in Depth. Equipped with flip up cover, lift out safety screens, 2¾" OD motor shaft, 2" wide x ¼" thick (outer) and 2½" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 12.3 Hp motor. Mounted on stainless steel (4) leg frame with 40" wide x 133" long stainless steel platform set 67" off the ground with 36" high rails and a 7-step staircase.
OAD: 136"L x 103"W x 109"H
Morcos, Model RM600, 21 ft³, (17 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 60" in Length; 24" in Width; 26" in Depth. Equipped with flip up cover, lift out safety screens, 2¼" OD motor shaft, 1¾" wide x ¼" thick (outer) and 1¾" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 7.38 Hp motor. Mounted on stainless steel (4) leg frame with 35" wide x 121" long stainless steel platform set 57" off the ground with 36" high rails and a 6-step staircase.
OAD: 125"L x 102"W x 103"H
Morcos Machinery Model STKK24, 24 inch wide x 24 feet long convection cooling tunnel with number of product per hour – depending on materials and application. Equipped with stainless steel frame and cladding contact parts, 3 foot In feed table with adjustable approach edge, 24" wide x 24′ long pneopreme product belt, has its own motor drive, centering device with automatic belt tracking and tensioning, drive station with speed inverter and spring loaded scrapers for roller self cleaning. 8 section tunnel with hinged gas spring assit flip up covers, with temperature gauges and height up to 60mm or 2.36". Built in air cooling units one unit for each zone (1) complete 3.5 Kw cooling system with humidity control and cooling air is delivered in loops by forced cold air streams through twin blowers with (2) independent adjustable cooling zones, cooling compressor, air cooled condenser, with frequency inverter and evaporator. Control panel has blower and belt on / off and speed controls with e-stops. Mounted on heavy duty frame.
OAD: 389" L x 42" W x 44" H
Morcos, 316 stainless steel 250 liter capacity blending tote / bin. Vessel dimensions: 35" diameter x 24" deep with a 12" straight wall. Equipped with lift off cover with (1) 10½" diameter and (1) 2" diameter ports and 4" ID butterfly valve discharge with 5½ ground clearance. Mounted on (3) legs with locking casters.
OAD: 43"L x 37"W x 37"H
