PMI, Model VXL2-15, automatic, inline, servo driven, case packer. Rated from 5 to 13 cases per minute with number of product – depending on materials, application and pack pattern. Case size range: 5" to 10" in Length x 4" to 7" in Width x 3" to 6" in Height. Equipped with product infeed conveying section, 64" long blank case magazine, fixed case pockets set on 7½" centers, hot melt glue system, bottom case sealer with bottom compression, 12" x 10" product accumulation table with sweeping arm loader, top case sealer and 8" wide x 58" long discharge conveyor. Control panel with AB PLC and touch screen HMI.
OAD: 180"L x 137"W x 94"H
PMI, Complete, automatic, continuous motion, servo driven, horizontal cookie packaging line with number of cartons and product per minute – depending on material and application. Equipped with (2) right angle turn product in feed conveyors with 96" long x 2" wide belts, to (2) product transfer conveyors (1) 162" long and (1) 130" long with 7-1/2" wide belts and 9-1/2" long x 9-1/4" wide x 5" deep fixed product buckets, dual robotic (3) head with 10 suction cups each product pick n place machines. PMI Model FB-PK-HS-02311, automatic (4) chains adjustable, horizontal cartoner set on 15" centers with 2-1/4" high x 4-1/2" high lugs, 64" long automatic single belt blank carton magazine, (3) head rotary pic-n-place with top product hold down, barrel cam loader, Nordson ProBlue hot melt glue system, carton flap tuckers and closing belts, no-carton, no-fill and no-product, no-carton controls with side compression and discharge belts. Control panel has A/B controls and A/B swing arm controller with panel view and has start, stop, reset and e-stop push buttons with statis lights bars. All Mounted on heavy duty frames with interlock safety guarding and leveling legs.
Markem Lazer Coder Available At Additional Cost
OAD: 596" L x 112" W x 94" H Total Line
PMI, Automatic, continuous motion, vertical, hot melt glue cartoner with number of cartons per minute – depending on materials and application. Carton size range: per application with proper change parts. Equipped with 58" long single belt powered blank carton magazine, (4) head rotary pic in place, has 1 chain with 2" Long x 3" Wide x 1/4" Deep fixed product buckets set on 4" centers, 6 head rotary product funnel filler with Nordson hot melt glue system, major and minor flap closers, compression and discharge section. Control panel has A/B CPU controller with Panel View controls and e-stop push buttons. Mounted on heavy duty frame with leveling legs, interlock safety door guarding and statis light bar.
OAD: 122" L x 50" W x 65" H Cartoner 58" L x 5" W Carton Magazine
PMI Model VS2-15 Semi – automatic, vertical, hand load, hot melt glue cartoner with number of cartons per minute – depending on materials, application and operator dexterity. Carton size range: per application with proper change parts. Equipped with 72" long (2) chain powered blank carton magazine, (3) head rotary pic in place, 1 chain fixed set on 15" centers, 72" long operator hand load area each side of machine, Nordson ProBlue hot melt glue system with major and minor flap closures, compression section and discharge conveyor. Control panel has A/B CPU controller and A/B swing arm panelview controls with start, reset, stop and, e-stop push button controls. Mounted on heavy duty frame with leveling legs and interlock safety door guarding.
OAD: 240" L x 80" W x 74" H Cartoner 72" L x 6" W Carton Magazine
PMI Model Automatic, horizontal, continuous motion, hot melt glue cartoner rated from 30 to 300 cartons per minute – depending on materials and application. Carton size range: Per application. Equipped with (3) chains adjustable, set on 7" centers with 2" wide x 2-1/2" high lugs. 384" long product in feed conveyor with 5" long x 3-1/2" wide x 11" deep fixed product buckets, 70" long, single belt, automatic blank carton magazine with (4) head rotary pick n place, barrel cam loader, overhead product confiner, no product / no carton detector, Nordson ProBlue hot melt glue system, with major and minor flap closers and 36" long side belt compression and discharge conveyor. Control panel has A/B PLC controller and A/B panelview controls with operator interface, start, stop, reset and e-stop push buttons with statis light bar. Mounted on heavy duty welded steel base frame with leveling legs and safety guarding.
OAD: 288" L x 120" W x 82" H Cartoner 384" L x 20" W x 38" H Infeed Conveyor
PMI Cartoning, Model 96200800, inline, servo controlled carton upender. Rated from 20 to 300 cartons per minute – depending on materials, application and machine configuration. Equipped with 28" diameter up ending star wheel with vacuum suction cups and a 45" long (2) chain lugged take away conveyor set on 9" centers. Control panel with independant servo controllers for starwheel / lugs and push button stop / stop controls. Mounted on base frame with safety guarding.
OAD: 111"L x 42"W x 69"H
