Home » Resina
Resina, Model S30, Automatic single head chuck capper. Rated from 20 to 55 containers per minute – depending on materials, application and machine configuration. Cap size range: 13mm to 70mm. Containers size range: up to 6" in Diameter and 6" to 15" in Height, change parts required for different size ranges. Equipped with 96" long x 4½" wide stainless steel container conveyor, cap hopper with disc pin sorter, cap chute, transfer shoe and cap button, dual container grippers and single head chuck style cap tightner. Control panel has touch screen HMI.
OAD: 100"L x 52"W x 102"H
Stainless steel, 2 station capper rated from 40 to 120 cpm – speeds depending on materials and application. Cap size range of: 10mm – 70mm. Equipped with a 93"L x 4 1/2"W conveyor, cap hopper, cap sorting disc cap chute and barrier guarding with interlock.
OAD: 98"L x 45"W x 93"H
Resina Model F14, automatic, fitment applicator rated from 120 to 300 containers per minute – depending on materials and application. Fitments: 20mm to 38mm in Diameter. Containers: 2-1/2" to 5" in Height Equipped with 3.5 cu. ft. cap hopper, 22" diameter cap sorting wheel, cap feed chute, container indexing bumps wheels, 11" long side gripper wheels during cap application, 2-1/4" wide drum fitment applicator, and start / stop push button controls. Mounted on height adjustable feet. Speeds: snap caps 300 per minute, sauce fitments 250 per minute, granular products 120 per minute
OAD: 70"L x 39"W x 79"H
Resina, Model S, Automatic, inline, stainless steel, single head chuck capper. Rated from 10 to 60 containers per minute – depending on materials and application. Cap size range: 13mm to 75mm. Container size range: up to 4½" in diameter; x 10" in Height with proper change parts. Equipped with 92" long x 4½" wide stainless steel belt conveyor with adjustable guide rails, cap hopper with disc sorter, cap chute, transfer button and single head chuck cap tightener. Control panel has drive, hopper, cap head, conveyor, and counter control dials, with vari speed controller with start, stop and e-stop push button controls. Mounted on a stainless-steel frame.
OAD: 96" L x 54" W x 85" H
Resina, Model S30, Automatic, inline, stainless steel, single head chuck capper. Rated from 10 to 40 containers per minute – depending on materials and application. Cap size range: 13mm to 70mm. Container size range: up to 4½" in diameter; x 10" in Height with proper change parts. Equipped with 66" long x 4½" wide stainless steel delrin belt conveyor, cap hopper and disc sorter, with cap chute, transfer button and single head chuck cap tightener. Control panel has drive, hopper, cap plunger head, conveyor and counter control dials, vari speed controller with start and stop push button controls. Mounted on heavy duty frame.
OAD: 72" L x 48" W x 85" H
Resina, Model NRS-51HES LH, Left to right, single head chuck capper and cap feeder rated up to 60 containers per minute – depending on materials and application. Cap size range: 70mm to 120mm, with proper change parts. Equipped with 4½" wide x 120" long container conveyor, 39" wide x 24" long x 30" deep Model HES bulk cap hopper and feeder has 17½" wide elevator belt conveyor with cleats set on 5" centers. Control panel has touch screen HMI with start, stop and e-stop controls. Mounted on heavy duty frame with safety guarding and adjustable leveling legs.
OAD: 126" L x 44" W x 80" H Capper 56" L x 53" W x 82" H Feeder
Resina Model, UN40, Automatic, 4 station, 8 spindle, stainless steel, capper. Rated from 20 to 300 containers per minute – depending on materials and application. Designed to handle a wide variety of container and bottle sizes and shapes and to place caps onto containers ranging from 10mm to 70mm in width. Equipped with 84" long x 4½" wide stainless steel container conveyor, cap hopper and pin wheel sorter, 42" long x 1½" high double side gripper belts for container handling and stability, with 4 stations, 8 spindles cap tighting section set on 5" centers with adjustable clutches. Control panel has quill, gripper, conveyor and spacer speed control dials with e-stop. Mounted on heavy duty stainless steel frame with safety guarding.
OAD: 120" L x 48" W x 96" H
Resina Model U40, Automatic, 4 station 8 spindle, capper rated from 20 to 300 containers per minute – depending on materials and application. Stainless steel contact parts and is designed to handle a wide variety of container sizes, shapes and place caps onto containers ranging from 10mm to70mm. Equipped with inclined cleated cap feed conveyor with 32" x 36" x 18" hopper and 8" wide x 105" long belt with 2½" high cleats set on 9" centers, 128" long x 4½" wide stainless steel container conveyor, cap hopper and pin wheel sorter, 28" long x 1" high dual side container handling and stability gripper belts with 4 stations, 8 spindles cap tighting section set on 5" centers and has adjustable clutches. Control panel has quill, gripper, conveyor and spacer speed control dials with e-stop. Mounted on heavy duty painted frame.
OAD: 128"L x 42"W x 101"H (Capper) 96"L x 32"W x 125"H ( Feeder)
Resina Model N30, Automatic, intermittent, inline, single head chuck capper rated from 10 to 40 containers per minute – depending on materials, application and machine configuration. Cap size range: 13mm to 70mm. Container size range: up to 4-1/2" in diameter and up to 16" in Height. Equipped with 125" long x 4½" wide stainless steel delron conveyor, adjustable guide rails, cap hopper disc sorter, cap chute, cap transfer button, dual container grippers belts and single head chuck with no container / no cap. Control panel has start, stop, e-stop and hopper speed control. Interlock safety guarding. Mounted on mild steel base frame. Change parts required to accommodate size range of container and cap.
OAD: 135"L x 48"W x 91"H
Resina Model UN20, Automatic, 2 station, 4 spindle, stainless steel, cap retorquer rated from 40 to 100 containers per minute – depending on materials and application. Cap size range: 10mm to 38mm. Container size range: 1/2 oz to 1 gallon and up to 15" in Height. Equipped with cap hopper and pin wheel sorter, 36" long x 1" high double gripper belts for container handling and stability, with 2 stations, 4 spindles, with adjustable clutches. Control panel has quill, gripper, conveyor and spacer speed control dials with e-stop and interlock safety guarding. Mounted on heavy duty stainless steel frame.
OAD: ___" L x __" W x __" H
Resina Model S, automatic, inline, stainless steel, single head chuck capper rated from 10 to 40 containers per minute – depending on materials and application. Cap size range: 13mm to 70mm. Container size range: up to 4-1/2" in diameter x 10" in Height. Equipped with 153" long x 4" wide plastic delron container conveyor, with adjustable guide rails, cap bowl feeder. cap hopper with disc sorter, cap shute, cap transfer button and dual container grippers with single head chuck cap tightner, no container / no cap sensor eye, vari speed controller with start, stop, e-stop push button controls and interlock safety guarding. Mounted on base frame with height adjustable legs. Size range requires change parts per application.
OAD: 153" L x 47" W x 67" H
Resina, Model S, automatic, single head, chuck style capper rated from 5 to 40 containers per minute – depending on materials, application and machine configuration. Cap size range: 38mm to 89mm. Containers size range: up to 6" in Diameter; 2¾" to 13" in Height. Equipped with 4½" wide x 84" long stainless steel conveyor, cap hopper, cap sorter, cap chute, cap button, transfer shoe and double container grippers. Change parts required to accommodate size range.
OAD: 90"L x 60"W x 90"H
