Frain Industries has many Urschel machines in stock and ready to ship including dicers, slicers, shredders, Comitrol mills and other food processing and food cutting machinery.  We have Urschel machines for many applications including meat, dairy, vegetables, fruits, nutraceuticals, pharmaceuticals, chemical and others.
Urschel, Model Diversacut Q, QuantiCut, stainless steel, dicer, slicer, strip cutter with pounds of product per minute and hour – depending on materials and application. Maximum product input size is 10" (254 mm) in any dimension. The Model Q is a higher production model of the model GA. It will slice, strip cut, dice and crinkle cut with a combinations of different slice thickness, with the use of different circular knife spacing and interchangeable crosscut knife spindles. Slice of thickness: 1/8" to 1-1/8" (3.2 to 28.6mm), Circular Knives: 1/4" to 3" (6.4 to 6.2mm) Crosscut Knives: 1/8 to 2-5/8 in. (3.2mm to 66.7mm). Mounted on (4) legs with locking casters. Used for wide variety of products such as potatoes, carrots, turnips, rutabagas, pineapple, peppers, celery and many of other products.
OAD: 72"L x 75"W x 58"H
Urschel, Diversacut Sprint, stainless steel dicer uniformly dices, strip cuts, and slices a wide variety of products at high production capacities with speeds dependent on materials, application and machine configuration. Capable of handling product sizes up to 6½" in any dimension. Circular knife cuts: 1/8 to 3" (3.2 to 76.2 mm), Crosscut knife cuts: 3/32 to 1-1/2" (2.4 to 38.1 mm), Crosscut knife crinkle cuts: 9/32 to 9/16" (7.1 to 14.3 mm). Equipped with a 17" deep 16" x 17" rectangular hopper, 14" diameter x 7" wide product chamber, circular knives, cross cut knives, 1½HP drive and a 20" x 10" discharge chute with 15" ground clearance. Change parts required per application.
OAD: 54" L x 53" W x 66" H
Urschel Model H, stainless steel USDA, dicer / slicer / cutter for a variety of food products with volumes per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 1" Slice Thickness, 3/4" to 1-3/4" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5-1/2" in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls and is mounted on stainless steel base frame. Change parts required for size changes. Currently set for
Urschel Model 1700 Comitrol, stainless steel, reduction mill for free flowing dry and semi-dry product with number of pounds of product per hour – depending on materials and application. Equipped with 12" ID x 12" Deep product hopper 17" OD x 17" milling chamber with (3) 3" dog leg style high speed rotating impeller and cutting head with vertical blades and 4-1/2" OD triclover product inlet and 3-1/2" triclover product discharge with 30 Hp motor drive. Control panel has push botton start, stop, auto and manual control switches. Mounted on stainless steel base frame. Operations include communiting, granulating, milling, slicing, liquifying, dispersing, and pureeing.Change parts required per application.OAD: 48" W x 33" L x 66" H
Urschel, Model TRS2000, stainless steel slicer used for a variety of food products with number of pounds of product per hour – depending on materials and application. Equipped with 20" diameter cutting wheel, 96" long V-belt infeed with a 48" long load area and variable speed controls for both the belt and wheel. Ideally suited for elongated firm products to 4" diameter and 6" diameter for compressible leafy products. Mounted on stainless steel (4) leg base frame with casters. Capable of flat slices, crinkle slices and julienne cuts. Change parts required to accommodate specific cut configuration
OAD: 130"L x 36"W x 56"H
Urschel, Model Diversacut 2110, stainless steel, dicer, slicer, strip cutter with inclined feeder used for a variety of food products with number of pounds of product per hour – depending on materials and application. Equipped with 13" x 12" product charge and has swing open locking access door with safety interrupt switch, has crosscut and circular knifes and accepts product up to 10" in any dimension and 13" x 12" discharge chute with 22" floor clearence. Control panel has start, stop and e-stop push button controls with 5 Hp stainless steel motor drive. Mounted on stainless steel base frame. Also has stainless steel, Inclined cleated feeder and hopper with 96" long x 12" wide neophreme product belt with 2-1/4" high lugs set on 6" centers with 76" discharge height.
OAD: 65" L x 55" W x 75" H Urschel 92" L x 38" W x 76" H Inclined Feeder
All S/S dicer uniformly dices, strip cuts, and slices a wide variety of products at high production capacities, and accepts products up to 10" in any dimension. Types of cuts slices: flat & crinkle slices: 1/16 to 1" Strip cuts: flat and crinkle minimum/maximum flat strips 1/8 x 1/8" to 1 x 1" x length of product. Crinkle strips 9/32 x 9/32" length of product. Circular knife cuts: 1/8 to 3" Crosscut knife cuts: 1/8 to 1-1/2" Crosscut knife crinkle cuts: 9/32 to 5/8" Change parts required to accommodate size range.
OAD: 64"L x 64"W x 62"H
Urschel Model M6, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and is capable of production rates from 500 to 4,500 lbs. per hour – depending on materials, application and machine configuration. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 9" load area on feed belt and adjustable feed roll allowing for positive product feed at all thicknesses from 3/8" to 1". Change parts required to accommodate size range.
OAD: 120"L x 35"W x 43"H
Urschel Model CCD, stainless steel, slicer, strip cutter, shredder and crinkle cutter used for a variety of different food products with production rates with volumes per hour – depending on materials, application and machine configuration. Flat Slices: 0.8mm to 12.7mm, Standard Crinkle: 3-1/3 to 5.7 waves per inch Depth of Crinkle: 2.0mm to 2.1mm, Thickness: .040mm to .285mm, V-Slices 4.7 to 8 waves per inch Depth of Crinkle: (4.7) 2.1mm, Thickness: 1.0mm to 2.5mm. Depth of Crinkle (8)1.3mm, Thickness: 1.0mm to 2.5mm. Also does Oval, Cresent Shreds and strip cuts (all with proper change parts). Equipped with centrifical type slicer utilizes rotating impeller to force the product to the side walls and thru (8) individual inter-changeable cutting heads that enable the processor to change the type of cuts in minutes and has inexpensive to replace, specially designed throw away knives. Accept products up to 3-1/2" in any dimension. Stainless steel feed hopper, discharge chute and start / stop push buttons controls. Mounted on push cart with casters
OAD: __" L x __" W x __" H
Urschel Model G, stainless steel USDA, dicer / slicer / cutter used for a variety of food products with volumes per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 5/8" Slice Thickness, 9/32" to 3" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5-1/2" in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls. Mounted on stainless steel base frame with casters. Change parts required for different size changes.
OAD: 64"L x 32"W x 60"H
Urschel, Model G, stainless steel dicer / slicer / cutter with inclined feeder used for a variety of food products with number of pounds of product per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 5/8" Slice Thickness, 9/32" to 3" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5½"in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls and is mounted on stainless steel base frame. Change parts required for size changes. Also has stainless steel, Inclined cleated feeder and hopper with 89" long x 24" wide neophreme product belt with 2-1/2" high lugs set on 12" centers with 59" discharge height.
OAD: 75" L x 50" W x 50" H Urschel 107" L x 54" W x 59" H Inclined Feeder
USDA approved dicer speeds vary depending on type of product used. Unit is capable of slicing 8000 Lbs/Hr of Pineapple at high speeds and 5000 Lbs/Hr of Macadamia nuts at high intermediate speeds. Unit will cut pieces as small as 1/16" X 1/8" X 1/16" and as large as 3/8" X 1/2" X 3/4". To cut different size pieces change parts are needed. Last running Mozzarella cheese in cubes. Unit is all stainless steel USDA approved. Change parts required to accommodate size range.
