Feldmeier Tank Processors 1000JKT

• Manufacturer: Feldmeier
• Model: 1000JKT
• Category: Stainless Steel Tank
• Subcategory: Stainless Steel Processor

Feldmeier, 1000 gallon capacity, stainless steel jacketed and insulated process tank. 316L stainless steel contact parts and 304 stainless steel jacket and exteroir parts. Vessel dimensions: 72" diameter with 60" straight wall. Equipped with dome top, 18" OD flip top man way, top mounted 7½ Hp side and bottom scrape surface agitation, baffle, (2) CIP spray balls supplied by 2"OD / 1½"ID Tri-clamp fittings and thermowell. Dish bottom has 3½" OD / 3" ID center bottom ball valve discharge with 18" ground clearence. Control panel with push button start / stop and variable speed control. Mounted on (4) legs with foot pads.

Nat’l Brd: 11778
MAWP: 150 PSI @ 350°F
MDMT: -20°F @ 150 PSI

Top Ports:
(2) 3½"OD / 3"ID Tri-Clamp

Jacket Ports:
(4) 1½" NPT

OAD: 82" L x 78" W x 133" H
