Lee Kettle Double Motion 2000LD9MS

• Manufacturer: Lee
• Model: 2000LD9MS
• Category: Kettle
• Subcategory: Double Motion

Lee, Model 2000LD9MS, 316 stainless steel 528 gallon jacketed vacuum kettle. Vessel Dimensions: 62" ID with a 27" straight wall. Equipped with an 18" ID diameter bolt down manway with 2"OD / 1½"ID Tri-Clamp, flush mount sensor, removable spray balls. Top mounted 15 Hp scrape agitator. Dome bottom with 4"OD / 3½"ID Tri-clamp discharge and 30" ground clearance. Mounted on (3) tubular leg frame.

Top Ports:
(7) 2"OD / 1½"ID Tri-Clamp
(2) 4"OD / 3½"ID Tri-clamp w/ Removable Spray Balls
(1) 6" OD / 5½"ID Tri-clamp
(2) 3"OD / 2½"ID Tri-Clamp

Bottom Ports:
(1) 2" NA connection

Jacket Ports:
(4) 2" NPT

MAWP: 90 PSI @ 332° F (Jacket)
MDMT: -20°F @ 90 PSI (Jacket)

MAWP: 25 PSI @ 268° F (Vessel)
MDMT: -20°F @ 25 PSI (Vessel)

Nat’l Brd: 14423

OAD: 90"L x 67"W x 143"H
